Fig. 1 · Structure

Documents & Downloads

PF-04691502

Cat. No. A11024 CAS 1013101-36-4

PI3K/mTOR Inhibitor

PF-04691502 is a PI3K/mTOR kinase inhibitor, is also an agent targeting the phosphatidylinositol 3 kinase (PI3K) and mammalian target of rapamycin (mTOR) in the PI3K/mTOR signaling pathway.

In Stock

Publications for PF-04691502

1 publication citing this product

  1. Yusuke Murase, .et al. , Oncol Rep, 2022, Apr;47(4):61 PMID: 35088890

Free Aliquoting for Your Order

Tell us your preferred amount per vial. We’ll confirm the options.

Biological Activity

Bioactivity / Mechanism

PF-04691502 modulated PI3K/mTOR-associated signaling in PIK3CA H1047R colorectal cancer stem-cell cultures: 0.1–1 µM reduced AKT Ser473 phosphorylation over 3–48 h. Partial recovery occurred at 48 h at 0.1 and 0.5 µM, while ERK Thr202/Thr204 phosphorylation remained unchanged. [1]

Literature-reported observations and conditions; not Adooq-tested protocols or general treatment recommendations.

Target & Activity

Target Activity Value
PI3Kδ ki 1.6nM
PI3Kα ki 1.8nM
PI3Kγ ki 1.9nM
PI3Kβ ki 2.1nM
P-Akt(S473) IC50 3.8nM
P-Akt(T308) IC50 7.5nM
mTOR ki 16nM

7 targets · Scroll to view more

Cellular Effect

Cell Line Activity Value Description Reference
BT-20 IC50 13 nM Inhibition of AKT phosphorylation at S473 in human BT20 cells after 1 hr by sandwich ELISA 10.1039/C0MD00072H
NCI-H460 IC50 0.2 μM Cytotoxicity against human NCI-H460 cells after 96 hrs by MTT assay [PMID: 29927604]
SK-OV-3 IC50 0.29 μM Antiproliferative activity against human SKOV3 cells after 3 days by CellTiter-Glo assay [PMID: 25139570]
SK-OV-3 IC50 7.4 nM Inhibition of AKT phosphorylation at S473 in human SKOV3 cells after 1 hr by sandwich ELISA 10.1039/C0MD00072H
U-87MG ATCC IC50 0.34 μM Antiproliferative activity against human U87MG cells after 4 days by Celltiter-Glo luminescence cell viability assay [PMID: 29305298]
U-87MG ATCC IC50 0.52 μM Antiproliferative activity against human U87MG cells after 4 days by CellTiter-Glo assay [PMID: 25139570]

In Vitro Studies

In a panel of 12 canine tumor cell lines, PF-04691502 reduced WST-1 viability after 96 h with heterogeneous concentration responses. Gedatolisib showed a lower median IC50 in the same panel; the paper’s subsequent gedatolisib mechanism experiments do not establish those effects for PF-04691502. [2]

Canine tumor-cell viability panel

Cell-based study · 12 canine tumor cell lines: POS, HMPOS, MCTCC, LCTCC, MegTCC, MomoTCC, CMeC, MCM-N1, DH82, CHS-4, CoMS and CLAC. [2]

PF-04691502 decreased WST-1 viability in a concentration-dependent, cell-line-dependent manner. Gedatolisib had a lower median IC50 in this panel; these comparator data do not establish PF-04691502-specific apoptosis or ABCB1 resistance.

Measured endpoints — not treatment concentrations
EndpointReported resultReference
WST-1 viability relative to control across 12 canine tumor cell linesqualitative dose response Concentration-dependent reduction with heterogeneous responses; mean ± SD of five replicates for dose-response curves.[2]

Literature-Reported Treatment Conditions

Treatment concentration
0.1 nM–10 µM
Exposure duration
96 h
Method
WST-1 viability; dose-response fitting with a three-parameter variable-slope sigmoidal model.
Vehicle
0.1% DMSO control
Co-treatment
Single-agent PF-04691502; other inhibitors, where present, were separate comparators.
Reported limits
Exact PF-04691502 IC50 values were plotted rather than numerically tabulated in the adopted figure; no exact values digitized.
Methods and source locations

Compound reported in the paper: PF-04691502

Model-specific research findings for PF-04691502; no claim that the current A11024 lot was tested.

Materials and methods: Inhibitors, Cell viability assay, Statistical analysis; Results first subsection; Figure 2A-B and caption

WST-1 viability relative to control across 12 canine tumor cell lines: WST-1; Figure 2A. Figure 2B plots fitted IC50 values and their median. — Materials and methods: Inhibitors, Cell viability assay, Statistical analysis; Results first subsection; Figure 2A-B and caption

Time-dependent AKT signaling response in colorectal CSCs

Cell-based study · Spheroid colorectal cancer stem-cell culture derived from a single patient tumor; PIK3CA H1047R. [1]

AKT Ser473 phosphorylation decreased at all tested concentrations. At 48 h it partially recovered at 0.1 and 0.5 µM but remained below the untreated control; pERK Thr202/Thr204 was unchanged. This is pathway modulation, not a direct biochemical binding assay.

Measured endpoints — not treatment concentrations
EndpointReported resultReference
pAKT (Ser473), with pERK (Thr202/Thr204) specificity comparisonqualitative phosphorylation response pAKT reduced; partial recovery at 48 h at 0.1 and 0.5 µM, remaining below control. pERK unchanged.[1]

Literature-Reported Treatment Conditions

Treatment concentration
0.1, 0.5 and 1 µM
Exposure duration
3, 24 and 48 h
Method
Western blot; zero-drug controls at each time point; GAPDH loading control.
Co-treatment
Single-agent PF-04691502; other inhibitors, where present, were separate comparators.
Reported limits
Vehicle and replicate count for Figure 5F are not specified in the relevant text/caption.
Methods and source locations

Compound reported in the paper: PF-04691502; Compound label in the paper: 502

Model-specific research findings for PF-04691502; no claim that the current A11024 lot was tested.

Results: Profound Antiproliferative Activity of PF-04691502 in Mutant CSCs; Figure 5F and caption

pAKT (Ser473), with pERK (Thr202/Thr204) specificity comparison: Western blot with GAPDH loading control; qualitative image/text assessment only. — Results: Profound Antiproliferative Activity of PF-04691502 in Mutant CSCs; Figure 5F and caption

In Vivo Studies

In a single-patient-derived PIK3CA H1047R colorectal CSC xenograft model, PF-04691502 at 10 mg/kg orally once daily for 14 days inhibited growth versus vehicle. Day-14 tumor volumes were 360±35 versus 1252±71 mm³ (mean ± SEM; n=8/group; reported P<0.01), with reduced tumor AKT Ser473 phosphorylation and unchanged ERK phosphorylation. [1]

Across six ovarian cancer xenograft models, oral PF-04691502 at 10 mg/kg/day on days 0–4, 7–11, 14–18 and 21–25 produced predominantly tumor growth stasis. Some models initially decreased in volume, but tumors regrew after dosing stopped, limiting interpretation as durable tumor control. [3]

Colorectal CSC-derived xenograft efficacy and tumor signaling

Animal study · Single-patient-derived colorectal CSC xenografts in SCID-bg mice; PIK3CA H1047R. [1]

Daily oral PF-04691502 inhibited tumor growth relative to vehicle and reduced tumor pAKT. The experiment did not demonstrate tumor eradication or a safety margin in normal stem cells.

Measured endpoints — not treatment concentrations
EndpointReported resultReference
Tumor volume at Day 14tumor volume 360±35 mm³ (PF-04691502) versus 1252±71 mm³ (vehicle); mean ± SEM; n=8/group; Results P<0.01.[1]
Tumor pAKT Ser473 and pERK Thr202/Thr204qualitative phosphorylation response pAKT reduced; pERK unchanged; four tumors per group for immunoblot/quantification; mean ± SEM in Figure 5E.[1]

Conditions shared by the study groups

Route
Oral (PO)
Frequency
Once daily
Treatment course
14 days
Vehicle
0.5% methylcellulose in water
Study groups and reported outcomes
Group / doseComparatorObserved resultReference
PF-04691502 monotherapy
10 mg/kg
Vehicle, same oral daily schedule; n=8.Day-14 mean tumor volume 360±35 mm³ versus 1252±71 mm³ in controls (mean ± SEM; Results P<0.01). Tumor pAKT was reduced and pERK unchanged. No treated mouse lost more than 20% body weight per Results; body weight decreased in both groups in Figure 5C.[1]
PF-04691502 monotherapy
Model: SCID-bg mice bearing PIK3CA H1047R colorectal CSC-derived xenografts; n=8 per treatment/control group.
Reported limits: Tumor sampling time relative to final dose not specified in the adopted methods/caption. Methods mention three randomized groups but identify only the two plotted arms; third group is unexplained.
Methods and source locations

Compound reported in the paper: PF-04691502; Compound label in the paper: 502

Model-specific research findings for PF-04691502; no claim that the current A11024 lot was tested.

Materials and Methods: In vivo Antitumor Efficacy Evaluation, Western Blot Analysis; Results: Tumor Growth Inhibition and Reduction of pAKT; Figure 5B-E and caption

Tumor volume at Day 14: Serial tumor volume; Figure 5B caption specifies two-way ANOVA (*P≤0.05; **P≤0.001). Values and P<0.01 are taken from Results, not inferred from the curve. — Materials and Methods: In vivo Antitumor Efficacy Evaluation, Western Blot Analysis; Results: Tumor Growth Inhibition and Reduction of pAKT; Figure 5B-E and caption

Tumor pAKT Ser473 and pERK Thr202/Thr204: Western blot with α-tubulin loading control. No exact percent decrease inferred. — Materials and Methods: In vivo Antitumor Efficacy Evaluation, Western Blot Analysis; Results: Tumor Growth Inhibition and Reduction of pAKT; Figure 5B-E and caption

PF-04691502 monotherapy · Materials and Methods: In vivo Antitumor Efficacy Evaluation, Western Blot Analysis; Results: Tumor Growth Inhibition and Reduction of pAKT; Figure 5B-E and caption

Ovarian xenograft growth response and regrowth

Animal study · Six patient-derived ovarian cancer xenografts in adult female CD-1 nude mice. [3]

PF-04691502 produced predominantly tumor growth stasis across the panel. Initial shrinkage in some models converted to stasis, and growth resumed after treatment stopped. Gedatolisib was a separate comparator, not a combination treatment.

Measured endpoints — not treatment concentrations
EndpointReported resultReference
Relative tumor growth during treatment and after discontinuationqualitative growth response Predominantly stasis; initial decrease in OV1002/HOX299, no initial decrease in HOX516; regrowth after cessation. Figure 1 reports mean ± SE and model-specific P<0.05 comparisons.[3]

Conditions shared by the study groups

Route
Oral gavage
Frequency
Days 0–4, 7–11, 14–18 and 21–25
Treatment course
Four weeks of scheduled treatment, followed by off-treatment observation.
Vehicle
0.5% carboxymethylcellulose in sterile distilled water
Study groups and reported outcomes
Group / doseComparatorObserved resultReference
PF-04691502 across six ovarian xenograft models
10 mg/kg/day
Untreated control as labeled in Figure 1; not assumed to be a vehicle-dosed control.Growth was predominantly static during treatment. OV1002 and HOX299 showed an initial volume decrease; HOX516 showed stasis without an initial decrease. Tumors regrew after treatment cessation.[3]
PF-04691502 across six ovarian xenograft models
Model: Adult female CD-1 nude mice bearing HOX552, OV1002, HOX516, HOX299, HOX424 or HOX493 xenografts; minimum 6 mice/group and at least 8 tumors/group.
Reported limits: Exact per-model mouse and tumor counts are not given in the read main text. Two tumors per mouse can be present; tumors are not independent animals. Randomization/blinding not specified in the read growth-study methods.
Methods and source locations

Compound reported in the paper: PF-04691502

Model-specific research findings for PF-04691502; no claim that the current A11024 lot was tested.

Results: Assessment of the antitumour activity of Gedatolisib and PF-04691502 against a panel of xenograft models; Figure 1 and caption; Methods: Xenograft studies; Discussion

Relative tumor growth during treatment and after discontinuation: Calipers; volume = π/6 × length × width². No exact curve values inferred. — Results: Assessment of the antitumour activity of Gedatolisib and PF-04691502 against a panel of xenograft models; Figure 1 and caption; Methods: Xenograft studies; Discussion

PF-04691502 across six ovarian xenograft models · Results: Assessment of the antitumour activity of Gedatolisib and PF-04691502 against a panel of xenograft models; Figure 1 and caption; Methods: Xenograft studies; Discussion

Specifications

Manufacturer Adooq Bioscience
Actions Inhibitor
CAS Number 1013101-36-4
Applications PI3K/mTOR Inhibitor
Formula C22H27N5O4
Molecular Weight 425.5
SMILES
COc1ccc(-c2cc3c(C)nc(N)nc3n([C@H]3CC[C@H](OCCO)CC3)c2=O)cn1

Storage & Solubility

In Vitro Solubility

Reported Solubility

SolventReported Solubility
DMSO 13 mg/mL (30.55 mM)
Water Insoluble
Ethanol Insoluble

Preparing Stock Solutions

Stock preparation is unavailable for this product molecular weight.

Calculated stock concentrations do not establish solvent solubility. Refer to the reported solubility data for experimental guidance.

Storage

Store powder at -20°C, keep desiccated.
In powder form, the chemical is stable for 36 months.
In solution, store at -20°C and use within 1 month to prevent loss of potency. Aliquot to avoid multiple freeze/thaw cycles.

Research References

  1. [1] Douglas D Fang, Cathy C Zhang, Yin Gu, et al. Antitumor Efficacy of the Dual PI3K/mTOR Inhibitor PF-04691502 in a Human Xenograft Tumor Model Derived from Colorectal Cancer Stem Cells Harboring a PIK3CA Mutation PLoS ONE (2013). PMID: 23826249 DOI: 10.1371/journal.pone.0067258 Source material
  2. [2] Yusuke Murase, Kenji Hosoya, Takachika Sato, et al. Antitumor activity of the dual PI3K/mTOR inhibitor gedatolisib and the involvement of ABCB1 in gedatolisib resistance in canine tumor cells Oncology Reports (2022). PMID: 35088890 DOI: 10.3892/or.2022.8272 Source material
  3. [3] Simon P. Langdon, Charlene Kay, In Hwa Um, et al. Evaluation of the dual mTOR/PI3K inhibitors Gedatolisib (PF-05212384) and PF-04691502 against ovarian cancer xenograft models Scientific Reports (2019). PMID: 31822716 DOI: 10.1038/s41598-019-55096-9 Source material

Publications

1 publication citing this product

  1. Yusuke Murase, .et al. , Oncol Rep, 2022, Apr;47(4):61 PMID: 35088890
