Vatalanib (PTK787) 2HCl

Cat. No. A10967 CAS 212141-51-0

VEGFR inhibitor

Vatalanib (PTK787 or PTK/ZK) is a small molecule protein kinase inhibitor that inhibits angiogenesis that inhibits all known VEGF receptors, as well as platelet-derived growth factor receptor-beta and c-kit, but is most selective for VEGFR-2. CAS: 212141-51-0 (HCl) 212141-54-3 (Free base)

In Stock

Publications for Vatalanib (PTK787) 2HCl

1 publication citing this product

  1. Ayaka Kojima, .et al. , Xenobiotica, 2022, Jul;52(7):669-675 PMID: 36251932

Free Aliquoting for Your Order

Tell us your preferred amount per vial. We’ll confirm the options.

Biological Activity

Target & Activity

Target Activity Value
VEGFR2/KDR IC50 37nM
VEGFR1/FLT1 IC50 77nM
VEGFR2/Flk1 IC50 270nM
PDGFRβ IC50 580nM
VEGFR3/FLT4 IC50 660nM
c-Kit IC50 730nM
c-Fms IC50 1.4μM

7 targets · Scroll to view more

In Vivo Studies

PTK787 dihydrochloride inhibited pathological retinal neovascularization in mice: 25 mg/kg twice daily for five days eliminated identifiable surface neovascularization in the examined sections. The lowest tested dose did not significantly reduce endothelial staining in the reported t-test. A separate neonatal experiment showed that 10 mg/kg/day also delayed normal retinal vascular development, a limitation of inhibiting developmental angiogenesis. [1]

Literature-reported observations and conditions; not Adooq-tested protocols or general treatment recommendations.

Dihydrochloride inhibits pathological retinal neovascularization

Animal study · C57BL/6J mice with oxygen-induced ischemic retinopathy; P12–P17 treatment [1]

At 25 mg/kg twice daily, retinal sections lacked surface neovascularization and deep capillary beds. Lower doses gave graded effects; the lowest dose did not significantly reduce endothelial staining in the reported t-test. Normal vascular development was also affected.

Measured endpoints — not treatment concentrations
EndpointReported resultReference
Endothelial cells above the internal limiting membraneHistological presence/absence None identifiable at 25 mg/kg twice daily; deep capillary beds also absent[1]
Area of retinal endothelial-cell stainingDose response Significantly reduced at 2.5 and 25 mg/kg twice daily; lowest dose not significant by the stated paired t-test; dose-dependent trend P < 0.001 by ANOVA[1]

Conditions shared by the study groups

Route
Oral gavage
Vehicle
Shared method specifies aqueous buffer or DMSO depending on solubility, diluted with water (maximum 1% DMSO); exact PTK787 formulation is not assigned.
Study groups and reported outcomes
Group / doseComparatorObserved resultReference
PTK787 dose range
0.25, 2.5 or 25 mg/kg per dose
Vehicle-treated mice with ischemic retinopathy; nonischemic mice as referenceDose-dependent inhibition; complete absence of surface neovascularization at 25 mg/kg twice daily. Lowest dose did not meet the stated t-test significance threshold.[1]
Separate CGP 57148 and CGP 53716 comparator groups
120 μmoles/kg/day, as reported
Vehicle-treated ischemic miceNeither comparator showed an apparent decrease in neovascularization; CGP 57148 was also quantified. This observation alone does not validate target selectivity.[1]
PTK787 dose range
Frequency: Twice daily
Treatment course: 5 days, P12–P17
Separate CGP 57148 and CGP 53716 comparator groups
Frequency: Twice daily, per shared treatment method
Treatment course: 5 days
Reported limits: Comparator target-selectivity values are not adopted; one cited historical source is retracted.
Methods and source locations

Compound reported in the paper: Vatalanib (PTK787/ZK222584); Compound label in the paper: PTK787 dihydrochloride

Supports this salt in a mouse retinal model; no general efficacy or safety claim.

Materials and Methods: Drug Treatment of Mice with Ischemic Retinopathy; Quantitation of Retinal Neovascularization; Results: PTK787 Inhibits Retinal Neovascularization in Mice with Ischemic Retinopathy; Figures 1–2

Endothelial cells above the internal limiting membrane: Lectin-stained retinal sections; vehicle-treated ischemic and nonischemic controls. — Figure 1E–F and associated Results

Area of retinal endothelial-cell staining: Thirteen sections per eye averaged as one experimental value. Figure 2E labels N=8 for each PTK787 group and each control. Exact bar heights not transcribed. — Figure 2E; Results paragraphs on 2.5 and 0.25 mg/kg twice daily

PTK787 dose range · Figures 1–2; associated Results

Separate CGP 57148 and CGP 53716 comparator groups · Figure 2A–E and associated Results

Dihydrochloride delays normal retinal vessel development

Animal study · Newborn C57BL/6J mice; treatment from P0 and assessment at P7 or P10 [1]

Daily subcutaneous treatment delayed the advancing retinal vascular front at both ages compared with vehicle. The superficial vasculature continued developing rather than being permanently prevented.

Measured endpoints — not treatment concentrations
EndpointReported resultReference
Distance from optic nerve to leading vascular frontBetween-group comparison Reduced at P7 and P10; P < 0.0001 at both ages[1]

Conditions shared by the study groups

Route
Subcutaneous injection
Frequency
Daily
Treatment course
Starting P0; P7 or P10 endpoint
Vehicle
Vehicle control reported; exact composition not specified for this subcutaneous experiment.
Study groups and reported outcomes
Group / doseComparatorObserved resultReference
PTK787 developmental exposure
10 mg/kg/day
Vehicle-injected neonatal miceRetinal vessel extension was delayed at both ages.[1]
PTK787 developmental exposure
Reported limits: Figure 3 caption contains PTK797 spelling; drug identity is PTK787 in Methods, Results and Figure 4.
Methods and source locations

Compound reported in the paper: Vatalanib (PTK787/ZK222584); Compound label in the paper: PTK787 dihydrochloride

Developmental vascular inhibition is a model-specific limitation of antiangiogenic activity.

Materials and Methods: Drug Treatment of Mice during Retinal Vascular Development; Results: PTK787 Inhibits Retinal Vascular Development; Figures 3–4

Distance from optic nerve to leading vascular front: Image analysis of fluorescein-dextran retinal flat mounts; four quadrants averaged per mouse. Each bar represents mean of 5 experimental values; caption states paired t-test. Exact distances and error-bar definition not supplied numerically. — Figure 4 and caption; Materials and Methods, Drug Treatment of Mice during Retinal Vascular Development

PTK787 developmental exposure · Figures 3–4; shared developmental methods

Specifications

Manufacturer Adooq Bioscience
Actions Inhibitor
CAS Number 212141-51-0
Applications VEGFR inhibitor
Formula C20H17Cl3N4
Molecular Weight 419.7
Synonyms Vatalanib; PTK787; PTK/ZK
SMILES
C1=CC=C2C(=C1)C(=NN=C2NC3=CC=C(C=C3)Cl)CC4=CC=NC=C4.Cl.Cl

Storage & Solubility

In Vitro Solubility

Reported Solubility

SolventReported Solubility
DMSO 77 mg/mL (183.45 mM)
Water 9 mg/mL (21.44 mM)
Ethanol 5 mg/mL (11.91 mM)

Preparing Stock Solutions

Stock preparation is unavailable for this product molecular weight.

Calculated stock concentrations do not establish solvent solubility. Refer to the reported solubility data for experimental guidance.

Storage

Store powder at -20°C, keep desiccated.
In powder form, the chemical is stable for 36 months.
In solution, store at -20°C and use within 1 month to prevent loss of potency. Aliquot to avoid multiple freeze/thaw cycles.

Research References

  1. [1] Hiroaki Ozaki, Man-Seong Seo, Keiko Ozaki, et al. Blockade of Vascular Endothelial Cell Growth Factor Receptor Signaling Is Sufficient to Completely Prevent Retinal Neovascularization American Journal of Pathology (2000). PMID: 10666398 DOI: 10.1016/S0002-9440(10)64773-6 Source material

Publications

1 publication citing this product

  1. Ayaka Kojima, .et al. , Xenobiotica, 2022, Jul;52(7):669-675 PMID: 36251932
